MULTI-PANEL BESPOKE ROOF GLAZING

Bespoke Modular
Rooflights

Bespoke modular rooflights for large openings and extensions, made from multiple glass panels with slim silicone joints and support where required.

Structural silicone
Oak, steel or glass
UK manufacture
10-year IGU seal warranty
Technical support
Installed by Overhead Glazing

Modular rooflights for large openings and extensions

Key features.

Arrangement

Multiple insulated glass units

Joints

Weather-sealed structural silicone

Support

Project specific Aluminium, Stee, Timber or Glass Beam

Glass

Clear, Solar Control, Privacy Frosted

Inner pane

Heat treated laminated safety glass

Outer pane

Heat soak tested toughened glass

CLEAR DETAILS. EASY CHOICES.

Find what you need.

Product information, installation
and documents in one place.

MODULAR ROOFLIGHTS

Designed for your project.

A modular rooflight uses multiple insulated glass units to cover a large opening, such as the full length of a kitchen side extension. Splitting the opening can allow a lighter glass specification where the design permits, reducing the weight of each panel and potentially lowering manufacturing and delivery costs.

Support can become part of the architecture. These installation photographs show a modular rooflight carried by exposed oak beams and a frosted modular installation using slim silicone joints for privacy.

JOINTSStructural silicone
SUPPORTAluminium, Steel, Timber or Glass Fin
GLASSClear, Solar Control, Obscured Privacy
THE COMPLETE SYSTEM

Specification at a glance.

Arrangement
Multiple insulated glass units
Joints
Weather-sealed structural silicone
Support
Project-specific oak, steel or glass beam
Glass
Clear, solar-control or frosted options
Inner pane
Heat-treated laminated safety glass
Outer pane
Heat-soak-tested toughened glass
Finish
Standard or custom RAL colour

Panel sizes, support centres, glass build-up and joint widths are confirmed against project loads, geometry, access and installation sequence.

YOUR PROJECT. YOUR OPTIONS.

Choose the right glass and finish.

01

Exposed oak support

Panel divisions can align with expressed timber beams so the support becomes part of the finished interior.

02

Steel support

Project-specific RHS or other steel members can carry larger spans and coordinate with the building structure.

03

Frosted glass

Obscured glazing helps provide privacy for basements and lower-ground rooms.

04

Solar control

Coatings can help manage heat gain and glare across large areas of overhead glass.

FROM ENQUIRY TO INSTALLATION

Installed exclusively by Overhead Glazing.

This specialist system is supplied with installation by Overhead Glazing. We coordinate the approved detail, delivery, lifting and fitting; the quotation states the included work.

01

Review the opening

Send plans, sections, dimensions, support information and the intended internal appearance.

02

Set the panel layout

We coordinate glass sizes, joint positions and support centres around practical limits and sightlines.

03

Approve the details

Project drawings confirm glass, joints, frame, support and interfaces before manufacture.

04

Plan the installation

Delivery, lifting, pane sequence and final structural silicone seals are coordinated for the site.

The roof structure, prepared upstand, waterproofing, lifting and access responsibilities are agreed with your project team before work begins.

YOUR PROJECT PRICE

Quoted to your specification.

Based on the glass, dimensions and agreed service.

LEAD TIME

Agreed for your project.

Programme confirmed after specification and drawing review.

OUR SPECIALIST TEAM

Installation

Fitting, access and lifting requirements agreed with your project team.

Final cost and programme are confirmed for your specification and agreed scope.

OVERHEAD GLAZING IN MOTION

See our rooflight work.

Installed flat rooflight on a completed home
Play film

THE DETAIL MAKES THE DIFFERENCE

Slim joints. Clear alignment.

Structural silicone joints create a weather-sealed transition between adjacent glass units without bulky external pressure plates across the glazing.

Frosted modular roof glazing with slim joints

PERFORMANCE WITH CONTEXT

Performance for your project.

Glass, frame, support and intended use are considered together.

Prefer one glazed unit?

A large single-unit rooflight can reduce the number of visible joints where glass limits, support and site access allow. Modular glazing is an alternative when the opening needs to be divided into practical panels.

Privacy without losing daylight

Frosted glass can diffuse views into lower-ground rooms while continuing to admit useful natural light.

Designed around the support

Oak beams, steel members or a glass beam can be coordinated with the panel layout and internal sightlines.

Confirmed for your project

Panel sizes, support centres, glass build-up and joint widths are confirmed against project loads, geometry, access and installation sequence.

BEFORE YOU CHOOSE

Useful answers.

What is a modular rooflight?+

It is a large rooflight formed from two or more insulated glass units joined with weather-sealed structural silicone joints.

Do silicone joints need a pressure plate?+

The glass-to-glass joints can be detailed without an external pressure plate, creating a slimmer line between panels.

Can oak beams support the glass?+

Yes, where the timber structure is suitably designed and detailed. Glass positions and bearing details must be coordinated with the beams.

Can modular rooflights use frosted glass?+

Yes. Frosted or obscured glass can provide privacy while allowing diffuse daylight into the room below.

How are panel sizes chosen?+

They depend on loads, glass specification, production limits, access, lifting strategy and the supporting structure.

Do you install across the UK?+

Yes. We are London based and undertake suitable bespoke modular rooflight projects across the UK.

Can I order this rooflight supply-only?+

This specialist product is supplied with installation by Overhead Glazing only. Supply-only is available for suitable fixed flat rooflights.

What warranty applies to this product?+

Qualifying insulating glass units carry a 10-year seal warranty, subject to the written terms supplied with the order. This is not a blanket guarantee against breakage or a 10-year frame or installation warranty. Installation labour carried out by us is covered for five years, subject to the written terms.

CUSTOMER FEEDBACK

Hear from our customers.

Read feedback about Overhead Glazing on Google.

LET’S TALK ABOUT YOUR PROJECT

Planning a multi panel modular rooflight?

Share your postcode, drawings and project details. We’ll help confirm a suitable specification.

Installed exclusively by Overhead Glazing.
Optional. Up to 6 MB per file.

We’ll use these details to respond to your enquiry. Privacy policy

Your enquiry goes straight to our team.

PROJECTS & PRACTICAL ADVICE

From the drawing to the roof.

Frosted modular glazing for a lower-ground space.
PRODUCT IN CONTEXT

Frosted modular glazing for a lower ground space.

The multi-panel rooflight uses obscured glass and slim silicone joints to balance privacy with natural daylight.
